The ROS 2 Vision

"Unboxing"

Getting Started

Moving Outdoor

Quality of Service

Extend Capabilities: Hardware

Extend Capabilities: Software

Recap #1

• Multi-OS support: Linux, Mac OS, Windows
  • Binary packages for Mac OS and Windows
•
• Different client libraries share common implementation
•
• Quality of Service: variety of configuration options
  • DDS provides even more configuration options, directly accessible
•
• Hardware with "native" communication interface
        (no need for separate protocols and driver packages)
•
• Event based notifications (rather than need for polling)
• Remapping of topics at runtime
•

Undeterministic Startup

Lifecycle State Machine

Deterministic Startup

Coexistance with ROS 1

Usage Patterns of the "ros1_bridge"

• Beta
  • TurtleBot 2 demo
  • Robot using ROS 2 onboard
  • Computer uses ROS 1 tools,
    leverage existing ROS 1 packages
• Beta
  • HSR demo (see talk)
  • Robot using ROS 1 onboard
  • Computer uses ROS 2 tools,
    leverage intrinsic advantages
    of the communication protocol

Usage of the "ros1_bridge"

Usage Patterns of the "ros1_bridge"

• Beta
  • TurtleBot 2 demo
  • Robot using ROS 2 onboard
  • Computer uses ROS 1 tools,
    leverage existing ROS 1 packages
• Beta
  • HSR demo (see talk)
  • Robot using ROS 1 onboard
  • Computer uses ROS 2 tools,
    leverage intrinsic advantages
    of the communication protocol
•
  • Incrementally migrate a ROS system

Multi Robot

• Distributed discovery useful for on-demand robot-to-robot comm.
  • All current ROS middleware implementations support it
  • As long as all robots use the same comm. protocol
    they can communicate (independent of the vendor)
•
• Quality of Service settings to tailor the comm. for the specific scenario
  • (see eProsima's talk @ 11:35)
•
• Dynamic remapping of topics enables various different approaches, e.g.:
  • Flip namespaced robot spec. topics to be "global"
    • /robotA/pose → /pose
  • Subscribe to a specific topic from a group of robots
    • /**/pose    or    /floor2/*/pose

Adding a Custom Sensor

Flight Controller Internals

Recap #2

• Lifecycle nodes
• Basic Python-based launch files
  • Launch utilizing lifecycle state machine
•
• Dual-home bridge to exchange msgs / srvs between ROS 1 and ROS 2
  • More configuration options
•
• Multi robot benefiting from the communication protocol:
        distributed discovery, configurable QoS, dynamic remapping
•
• "Native" communication protocol with micro controllers (DDS-XRCE)
•
• Proof of concept for real time support using custom allocators
  • No usage of real time kernel yet, no continuous testing
•

Process Layout Decision

Fault Tolerance and Fallback Behaviors

Unsecure System

Securing the System

Validation and Certification

• Use certified hardware components (which talks DDS)
• Use certified DDS implementation
• Use certified / validated software components
•
• Select only the subsystems of ROS 2 which are required for the use case
• Build your own subsystem on top
•
• → Reduced effort to validate the custom application by
  • Using certified subsystem
  • Reducing footprint as much as possible
•



Recap #3

• Choose process layout at deploy time
  • Support from launch to easily configure this
•
• Event based system providing the infrastructure for fault detection,
        no tooling yet
•
• Security following the DDS-Security standard
  • Fine grain configuration
•
• None of the ROS 2 development is certified
  • But it can interoperate with certified implementations
•
